USB Device Redirection Introduction

Generic USB redirection feature allows redirection of arbitrary USB devices from client machines to XenDesktop virtual desktops. With this feature, the end users have the ability to interact with a wide selection of generic USB devices in their XenDesktop session as if it had been physical plugged into it.

Generic USB redirection works at a low level and redirect USB request and response message between client machines and XenDesktop virtual desktop. It avoids the requirement for compatible device drivers on the client machine and the driver is expected to be supported on the virtual desktop only.

Generic USB Redirection Configuration

Drivers Saxa Usb Devices Windows 10

By default, USB redirection configuration is not enabled. To use it, USB redirection policy and specific redirection rules must be enabled and configured.

Enabling Generic USB Redirection

1. Open Desktop Studio on XenDesktop server, click Start > All Programs > Citrix > Desktop Studio.

2. Expand HDX Policy.

3. Select Users.

4. Click Edit > Settings.

5. In the Policy console, scroll down to USB Devices.

6. Click Add on Client USB device redirection.

7. Select Allowed and click OK.

Creating USB Redirection Policy Rules

When the user tries to redirect USB device to Virtual Desktop, it is checked against each USB policy rules in turn until a match is found. The first match for any devices is considered final. If the first match is an Allow rule, the matched device is allowed to be redirected to the virtual desktop. If the first match is a Deny rule, the matched device is only available in the local desktop.

1. Open Desktop Studio on XenDesktop server and click Start > All Programs > Citrix > Desktop Studio.

2. Expand HDX Policy.

3. Select Users.

4. Click Edit > Settings.

5. In the Policy console, scroll down to USB Devices.

6. Click Add on Client USB device redirection rules.

7. Select Use default value and click OK.

   You can find the default rules in the following registry in virtual desktop:

   Caution! Refer to the Disclaimer at the end of this article before using Registry Editor.

   HKLMSOFTWARECitrixPortICAGenericUSBDeviceRules for 32-bit OS

   Or

   HKLMSOFTWAREWow6432NodeCitrixPortICAGenericUSBDeviceRules for 64-bit OS

Creating Client USB device optimization rules

In XenApp and XenDesktop 7.6 FP3, the Client USB device optimization rules can be applied to devices to disable generic usb optimization for interrupt devices, or to change the optimization mode.

When a user plugs in a USB input device, the host checks if the device is allowed by the USB policy settings. If the device is allowed, the host then checks the Client USB device optimization rules for the device. If no rule is specified, then the device is handled as Interactive mode (02). Capture mode (04) is the recommended mode for signature devices.

For more details follow link.

Settings for Audio redirection of XenApp (per user )

For Server OS enable audio through Generic USB from client policy, supported from Receiver 4.5 and XenApp / XenDesktop 7.8

For enabling audio redirection for logged in user you must perform following steps:

1. On Client copy receiver.admx from C:Program Files (x86)CitrixICA ClientConfiguration to C:WindowsPolicyDefinitions
   Note: For x86 Client instead of Program Files (x86) go to Program Files

2. On Client copy receiver .adml from C:Program Files (x86)CitrixICA ClientConfigurationen-US to C:WindowsPolicyDefinitionsen-US
   Note: For x86 Client instead of Program Files (x86) go to Program Files

3. On Client launch GPO by running gpedit.msc

4. Go to ComputerConfiguration->Administrative Templates->Citrix Receiver->User experience and right click edit “Audio through Generic USB Redirection”


5. Enable the policy and on client run gpupdate /force from command prompt


6. Launch XenApp session and redirect the audio device .

Settings for Specific USB Devices

Besides generic USB redirection, XenDesktop provides optimized redirection methods for some specific USB devices. Some advanced functions such as, data compression is provided by these dedicated virtual channels:

USB Device Type	USB Class Code	Dedicated Virtual Channel	USB Redirection Default Setting
Audio device	01h	RAVE	Disabled
Video device	0Eh	RAVE	Disabled
Printer	07h	Printing	Disabled
Mass storage	08h	CDM	Disabled
Image device	06h	TWAIN	Disabled Drivers siemens mobile phones & portable devices.
Smart card	0Bh	Smart card	Disabled
HID ( keyboard )	03h ( Subclass code = 01, prot=01 )	Keyboard	Disabled ( not recommend using USB redirection for keyboard )
HID ( Mouse )	03h ( Subclass code = 01, prot=02 )	Thinwire	Disabled ( not recommend using USB redirection for mouse device )

Using the USB Device Rules Policy

1. Open the Local Group Policy Editor and go to Administrative Templates > Citrix Components > Citrix Receiver > Remoting client devices > Generic USB Remoting.
2. Open the USB Device Rules setting and enable the setting. Add the USB Device rule as in this example,
   The Allow: VID=1230 PID=0007 rule allows the device with Vendor ID 1230 and Product ID 0007:
   Note:Use the Allow: VID=xxxx PID=xxxx rule when a specific device must be on top of the device rules list.

​
Note: Refer to Hardware/Device property details to find the Vendor ID or a tool like USBVIEW or on the Receiver Toolbar, go to Devices > Manage Devices > and mouse over on any device as shown in the following figure:

3. For Citrix Receiver 4.6 and lower, generally, the following USB Error appears when the device is in use on the endpoint. Identify the process using the device and kill it:

   “Device appears to be in use and cannot be attached. Close any…”

From Citrix Receiver 4.7 onwards, USB Error allows to forcefully redirect the device by clicking on Yes button

Drivers Saxa USB Devices

Workaround

Note: On Windows Receiver 3.0 version and later, there is a workaround to suppress the USB Error.

There is a registry setting available to force-redirect USB devices, even if a client-side application is using the device:

1. Open HKLMSOFTWARECitrixICA ClientGenericUSB for 32-bit OS.

   Or

   HKLMSOFTWAREWow6432NodeCitrixICA ClientGenericUSB for 64-bit OS.

2. Set REG_DWORD value EnableForceRestartForHID to 1.

Additional Resources

Drivers Saxa Usb Devices Download

Citrix Documentation - Configure USB support

For information on USB devices tested with XenDesktop, see CTX123569 - XenDesktop USB Citrix Tested Device List.

Improvements and fixes

This update includes a fix for an incorrect device driver (“Microsoft – WPD – 2/22/2016 12:00:00 AM - 5.2.5326.4762”) that was released by a third-party on March 8, 2017 that affected a small group of users with USB connected phones or other media devices that rely on Media Transfer Protocol (MTP). If the driver is on your system, when any of these devices are connected, Windows will try to install this driver. These devices will not be connected until the driver is removed. This incorrect driver was removed from Windows Update the same day, but it may have been downloaded to your computer. After installing this update the incorrect driver will be removed.
Drivers novation.

Drivers Saxa Usb Devices Free

How to get this update

This update will be downloaded and installed automatically from Windows Update. To get the stand-alone package for this update, go to the Microsoft Update Catalog website.

If you are not able to connect your phone or media device via USB and are not running one of these Windows versions, you can still remove this driver using the process described here:
